Specification

A16.0204 Reflected Fuorescence Microscope

Eyepiece

Wide field WF10X (Φ18mm)

Objective

Achromatic 4X/0.10

Achromatic 10X/0.25

Achromatic 100X/1.25(Spring, oil)

Fluorescence 25X/0.65

Eyepiece Tube

Trinocular (Inclination of 30°)

Focus System

Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm

Nosepiece

Quadruple(Backward ball bearing inner locating

Stage

Double layer mechanical (Size:135mmX125mm, Move range: 75mmX35mm)

Abbe Condenser

N.A.1.25 Rack & pinion adjustable

Filter

Frosted filter

Blue filter

Collector

For halogen lamp

Light Source

6V 20W halogen lamp, adjustable brightness

Reflected Fluorescence System

Mercury lamp house 100W/DC

Power supply unit:AV:110V or 220V

Fluorescence filter system B exciton wavelength:420~485nm

Fluorescence filter system G exciton wavelength:460~550nm

Optional Accessories

Item No.

Eyepiece

Wide field eyepiece WF16x/11mm

A51.0203-16A

Dividing 10x/20mm, 0.1mm/Div

A51.0205-G10

Objectives

Fluorescence objectives FL 40X/1.00 (Spring, Glycerin)

A5F.0205-40

Fluorescence objectives FL 100X/1.25 (Spring, Glycerin)

A5F.0205-100

Nosepiece

Quintuple (Backward ball bearing inner locating)

A54.0203-1

Filter

Green filter

A56.0209-2

Yellow filter

A56.0209-3

Fluorescence

100W fluorescence power supply(wide voltage and constant power and calculagraph)

A5F.0204-3

Reflected Fluorescence

Fluorescence filter system UV exciton wavelength:330~400nm

A5F.0201-UV

Fluorescence filter system V exciton wavelength:395~415nm

A5F.0201-U

Phase Contrast Unit

Eyepiece: centering telescope

A5C.0204-1

Phase contrast plan achromatic objective 10X/0.25 PHPl)

A5C.0211-10

Phase contrast plan achromatic objective 20X/0.40 PHP

A5C.0211-20

Phase contrast plan achromatic objective 40X/0.65 PHP(Spring)

A5C.0211-40

Phase contrast plan achromatic objective 100X/1.25 PHP(Spring, oil)

A5C.0211-100

(PH-I) Turnplate phase contrast condenser

A5C.0202-1

(PH-II) Turnplate phase contrast condenser

A5C.0202-4

Flashboard phase contrast condenser

A5C.0202-2

Pull board phase contrast condenser

A5C.0202-3

CCD Adapter

0.4X

A55.0202-01

0.5X

A55.0202-04

1X

A55.0202-02

0.5X with dividing 0.1mm/Div

A55.0202-03

DC Adapter

Digital camera adapter CANON (A610,A620,A630,A640)

A55.0204-01

Photo Adapter

2.5X/4X Change over photograph adapter with 10X viewing eyepiece

A55.0201-1

4X Focusing photograph adapter

A55.0201-2

MD Adapter

A55.0201-3

PK Adapter

A55.0201-4
