A19.0901

A

B

Optical System

Infinity Color Corrected Optical System

Head

Binocular, 45Incline, Gemel Head, Interpupillary

Distance 54-75mm

Trinocular, 45 Incline,

Gemel Head, Interpupillary

Distance 54-75mm

Eyepiece

High Eyepoint Wide Field Plan Eyepiece PL10x/22mm

Objective

Long Working Distance Infinity Positive Phase Contrast Plan Objective
Plan PH2 4x/0.13, W.D.=10.4mm
Plan PH2 10x/0.25, W.D.=6.9mm
Plan PH2 20x/0.40, W.D.=6.7mm
Plan PH2 40x/0.65, W.D.=3.0mm

Nosepiece

Revolving Quintuple Nosepiece

Stage & Holder

Fixed Stage Size: 250x160mm, Slider Clips, Extension Plate and

Coaxial Moveable Stage Can Be Assembled, Range 120x78mm, Various Holders:
--Glass Plate
--Metal Plate with
--Petri Dish Holder, Dia.35mm

Focusing

Coaxial Focus System with Up-limited and Tensen Adjustment,

Coarse Range 9mm, Fine Range 0.2mm, Fine Precision 0.002mm

Condenser

N.A.0.3 Kohler Illumination Condenser, with Phase Adjustable Slide Plate,

Long Working Distance 72mm. The Whole Set Can Be Rotated Down

Phase Contrast

Phase Contrast Slide, for 4x,10x,20x,40x, Center Adjustable
Centering Telescope Eyepiece

Filter

Dia.45mm Green Interference Filter
Dia.45mm Color Temperature Change Filter

Illumination

5W Ware Color LED, 12V/3.3A External Transformer, Intersity Adjustable

A19.0901

Optional Accessores

Stage Accessory

Mechanical Moving Scale, Moving Range 120X * 78Y mm
--Extended Plate
--Slide Holder, Dia.54mm and 26.5x76.4mm
--Teraseki Holder, Dia.65mm and 56x81.5mm

CCD Adapter

1x CCD Adapter, Focus Adjustable

0.5x CCD Adapter, for 1/2" CCD, Focus Adjustable

0.67x CCD Adapter, for 2/3" CCD, Focus Adjustable
